GZB-600
High Speed Paper Cup Forming Machine
GZB-600 High-speed paper cup forming machine is a machine that have double turntable, dual-segment high-performance with functions of automatic paper fan feeding, ultrasonic side seal, cup top lubrication, automatic bottom paper feeding, double curling artwork,automatic cup collect and stock.Can make cups both single PE and double PE,for cold drinks and hot drinks. This machine maximum speed can be 1 80pcs/min,stable running speed can bel 30-1 50pcs/min according to paper quality.
| Tatal Power | 13kw |
| Shipping Weight | 3660kg |
| Packing Specifications | L:2800mm×W:1400mm×H:1700mm (计杯架850mm×950mm×1700mm) |
| Electrical Specifications | 380v, 50Hz |
| Air Use | 0.5-0.8MPa, 0.5立方(Cubic)/min |
| Production Capacity | 130-150只(pcs)/min |
| Paper Size | 单(Singke)PE/双(Double)PE/PLA |
| Paper Weight | 210-330g/m模具成型纸张(Molding Paper)±20g/m² |
| Paper Bottom | (底/Bottom)Φ45-60mm;(高/H)60-135mm;(度数/Degree)4-7.5mm |
